4 IN 2 OUT MULTI-VIEWER

The ADP-MV-1117 is a professional-grade HDMI 4×2 Quad Multi-Viewer and Matrix Switcher. This device is designed to take four different HDMI input sources (like cameras, PCs, or media players) and display them simultaneously on two separate screens. | 4 IN 2 OUT MULTI-VIEWER

It is particularly valued in security monitoring centers, broadcasting studios, and high-end conference rooms because it supports a smooth 60Hz refresh rate, ensuring that motion remains fluid across all windowed views.

Key Features

• 4-In / 2-Out Configuration: Connect up to four input devices and route them to two independent displays.

• Quad-View Mode: View all four inputs on a single screen simultaneously. The screen is typically divided into four equal quadrants.

• Seamless Switching: Allows you to switch between full-screen inputs instantly without the 3–5 second “black screen” delay common in standard HDMI switches.

• Resolution Support: High-definition output up to 1080p @ 60Hz or 4K @ 30/60Hz (depending on the specific hardware revision).

• Matrix Functionality: Output A and Output B can often be configured differently—for example, Output A can show the Quad-view while Output B shows a single full-screen source.

Common Display Modes

Technical Specifications

• Input Ports: 4 x HDMI (Type A).¹

• Output Ports: 2 x HDMI (Type A).

•  Audio: Supports PCM 2.0 and often includes a separate 3.5mm or Toslink audio de-embedder to send sound to external speakers.

• Control Methods: Front panel buttons, IR Remote Control, and RS-232 serial control (for integration into automation systems).³

  Material: Heavy-duty metal housing for heat dissipation and durability in 24/7 environments.

Typical Use Cases

• Security: Monitoring four CCTV camera feeds on a single large monitor.

• Gaming/Streaming: Watching a walkthrough or chat on one segment of the screen while playing on the other.

• Command & Control: Viewing multiple data feeds (weather, traffic, news) in a single glance.
